A slip ring is a device used in rotating systems to enable the transfer of electrical power or signals from a fixed structure to a rotating one. Also known as a rotary interface, electrical rotary joint, swivel connector, or rotating contact assembly, it helps streamline mechanical designs by allowing free rotation without tangled or strained wiring. This not only enhances system efficiency but also reduces the chance of wire damage caused by constant motion.

Key Features :

• Each circuit supports 2 amps at 240 VAC or VDC
• Gold-on-gold contact design for extended operational life
• Compatible with various data bus communication protocols
• Optional sealed versions available for added protection
• Flexible, silver-plated wires with color-coded insulation
• Capable of transmitting both analog and digital signals
• Housing includes a built-in flange for easy mounting
• Configurable with 5A and 10A power circuits along with 2A signal circuits

Advantages :

• Fast delivery available to meet urgent needs
• Supports continuous 360-degree rotation
• Capable of high-speed data transfer
• Can integrate additional custom components
• Operating speeds up to 300 rpm or more
• Handles both analog and digital signal transmission
