ASC Series
The Capsule Series Slip Rings from Sulal Technologies are engineered for precision signal and power transmission in compact rotating systems. Ideal for space-limited applications, they offer high reliability, low noise, and customizable circuit configurations.
Applications
- Surveillance and PTZ camera systems
- Robotics and automation joints
- Medical equipment and diagnostic tools
- Miniature rotating platforms
- Antenna and gimbal systems
- Consumer electronics and drones
- Precision instrumentation and test equipment
Capsule Sliprings
| Part | OD | CIRCUITS | CURRENT | VOLTAGE | LENGTH | Details |
|---|---|---|---|---|---|---|
| ASC06 | φ22.1 | 6 | 2A | 240V AC/DC | 18.6 | 27.9 | 39.7 | VIEW >> |
| ASC08 | φ22.1 | 8 | 2A | 240V AC/DC | 30 | VIEW >> |
| ASC12 | φ22.1 | 12 | 2A | 240V AC/DC | 35.7 | 26.4 | 47 | VIEW >> |
| ASC18 | φ22.1 | 18 | 2A | 240V AC/DC | 42.2 | 32.9 | VIEW >> |
| ASC24 | φ22.1 | 24 | 2A | 240V AC/DC | 51.6 | 42.3 | 62.9 | VIEW >> |
| ASC30 | φ22.1 | 30 | 2A | 240V AC/DC | 58.9 | 49.6 | 69.5 | VIEW >> |
| ASC36 | φ22.1 | 36 | 2A | 240V AC/DC | 66.6 | 57.3 | 75.7 | VIEW >> |
| ASC56 | φ25.1 | 56 | 2A | 240V AC/DC | 95.2 | 85.7 | 63 | VIEW >> |
| ASC76 | φ35.6 | 76 | 2A | 240V AC/DC | 118.1 | 105.7 | VIEW >> |
| ASC125 | φ54.1 | 125 | 2A | 240V AC/DC | 216 | 200 | | VIEW >> |
Miniature Capsule Sliprings
| Part | OD | CIRCUITS | CURRENT | VOLTAGE | LENGTH | Details |
|---|---|---|---|---|---|---|
| ASM-04 | φ12.6 | 4 | 1-2A | 110V AC/DC | 18 | 15.6 | VIEW >> |
| ASM-06 | φ12.6 | 6 | 2A | 110V AC/DC | 20.6 | 18.2 | VIEW >> |
| ASM-12 | φ12.6 | 12 | 1-2A | 110V AC/DC | 27.6 | 26.5 | 25.2 | 24 | 35 | VIEW >> |
| ASM-18 | φ12.9 | 18 | 1-2A | 110V AC/DC | 27.5 | 23.5 | VIEW >> |
| ASM-24 | φ15.6 | 24 | 1-2A | 110V AC/DC | 40.4 | 34 | VIEW >> |
| ASM-30 | φ16.1 | 30 | 1-2A | 110V AC/DC | 44.25 | 37 | VIEW >> |
